| Item |
NTPL-OLTEPN210G |
NTPL-OLTEPN410G |
NTPL-OLTEPN810G |
NTPL-OLTEPN1610G |
| Chassis |
Rack – 1U 19 inch standard box |
| Uplink Port (1000M) |
4 |
8 |
16 |
12 |
| Copper (10/100/1000M auto-negotiation) |
2 |
4 |
8 |
4 |
| SFP 1000M Duplex (Independent) |
2 |
4 |
8 or 4 |
8 or 4 |
| SFP+ (10GE Independent) |
0 |
0 |
4 |
4 |
| EPON Port (QTY) |
2 |
4 |
8 |
16 |
| Physical Interface |
SFP Slot |
| Connector Type |
1000BASE-PX20+ |
| Max Splitting Ratio |
1:64 |
| Management Ports |
1*10/100BASE-T out-band port, 1*CONSOLE port |
| Transmission Distance |
20KM |
| EPON Port Speed |
Symmetrical 1.25Gbps |
| Wavelength |
TX 1490nm, RX 1310nm |
| Connector |
SC/PC |
| Fiber Type |
9/125μm SMF |
| TX Power |
+2~+7dBm |
| RX Sensitivity |
-27dBm |
| Saturation Optical Power |
-6dBm |
| Management Mode |
SNMP, Telnet, CLI, WEB |
| Layer 2 Switch |
16K Mac addresses, 4096 VLANs, VLAN tagging, QinQ, Storm Control, Port Isolation, QoS |
| Multicast |
IGMP Snooping, 256 IP Multicast Groups |
| DHCP |
DHCP Server, DHCP Relay, DHCP Snooping |
| Layer 3 Route |
ARP Proxy, Static Route, 1024 Host Routes, 512 Subnet Routes |
| EPON Functions |
Encryption, Multi-cast, VLAN, RSTP, ONU Auto-discovery, Remote Upgrade, ACL, SNMP |
| Dimension (L*W*H) |
442mm*200mm*43.6mm |
442mm*320mm*43.6mm |
442mm*320mm*43.6mm |
442mm*320mm*43.6mm |
| Weight |
3.1kg |
4.2kg |
4.5kg |
6.5kg |
| Power Supply |
220VAC (AC:90~264V, 47/63Hz, Dual Power Module Hot Backup) |
| Power Consumption |
25W |
30W |
52W |
102W |
| Operating Environment |
Working Temperature: -10~+55°C, Storage Temperature: -40~+85°C, Relative Humidity: 5~90% (non-conditioning) |
| Access Mode |
10/100Mbps |
| Standard |
IEEE 802.3 10BaseT; IEEE 802.3u 100BaseTX; IEEE 802.3x Flow Control; IEEE 802.1af/at |
| POE |
IEEE802.3af/max.15.4W; IEEE802.3at/max.25.5W |
| POE Line |
End-Span(12+,36-); Mid-Span(45+,78-) |
| Wavelength |
1310nm in both Tx and Rx port |
| Transmission Distance |
Multi-mode: 2 km; Single-mode:20~100km; Category-5 twisted pairs: 100m |
| MAC Address Table |
1K |
| Flow Control |
Full duplex: flow control |
| Delay |
Store-and-forward: 9.6μs; cut-through: 0.9μs |
| Power Supply |
AC100-240V 50HZ |
| Operating Temperature |
-10~55ºC |
| Operating Humidity |
10%~90% non-condensing |
| Maintaining Temperature |
40~70ºC |
| Maintaining Humidity |
5% ~ 90% non-condensing |
